| PU | LGA1155 socket for Intel 3rd/2nd Generation CoreTM i7, CoreTM i5, CoreTM i3, Pentium, and Celeron processors Supports Intel 22nm/32nm CPU Supports Intel Turbo Boost Technology 2.0 ⚫ Up to 77W Thermal Design Power support. ⚫ The Intel Turbo Boost Technology 2.0 support depends on the CPU types. • Refer to www.asus.com for Intel CPU support list. |
| Chipset | Intel H61 Express Chipset |
| Memory | 2 x DIMMs, max. 16GB, DDR3 1600/1333/1066 MHz, non-ECC, un- buffered memory Dual-channel memory architecture . Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List). . When you install a total memory of 4GB capacity or more, Windows 32-bit operating system may only recognize less than 3GB. We recommend a maximum of 3GB system memory if you are using a Windows 32-bit operating system. |
| Graphics | DVI-D with Max. Resolution: 1920x1200@60Hz D-SUB with Max. Resolution: 2048x1536@75Hz Max. UMA Memory: 1024MB |
| Expansion Slots | 1 x PCI Express 3.0*/2.0 x16 slot 2x PCI Express 2.0 x1 slots • PCIe 3.0 speed is supported by Intel 3rd generation Core processors. |
| LAN | Realtek 8111F PCIe Gigabit LAN controller |
| Storage | Intel H61 Express Chipset: - 4 x Serial ATA 3 Gb/s connectors |
| USB | Intel H61 Express Chipset: - 8 x USB 2.0/1.1 ports (4 ports at the mid-board, 4 ports at the back panel) |
| Audio | Realtek ALC887 8-channel High Definition Audio CODEC ⚫ Use a chassis with HD audio module in the front panel to support an 8-channel audio output. |
| Back Panel I/O Ports | 1 x PS/2 keyboard port (purple) 1 x PS/2 mouse port (green) 1 x DVI-D 1 x D-Sub 4 x USB 2.0/1.1 ports 1 x LAN (RJ-45) port 3 x Audio jacks |
| Internal I/O Connectors | 2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports 4 x SATA 3 Gb/s connectors 1 x 4-pin CPU fan connector 1 x 4-pin chassis fan connector 1 x Front panel audio connector 1 x System panel connector 1 x Speaker connector 1 x 24-pin ATX power connector 1 x 4-pin ATX 12V power connector 1 x Clear CMOS jumper |
| Software Features | ASUS Anti-Surge Protection ASUS UEFI BIOS (EZ Mode) ASUS MyLogo2 ASUS EZ-Flash 2 ASUS Fan Xpert ASUS AI Charger ASUS Crash Free BIOS3 ASUS AI Suite II ASUS Network iControl* ASUS Webstorage ⚫The Network iControl feature does not support Windows XP/Vista operating systems. |
| BIOS | 64 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM 2.0, ACPI v2.0a, SM BIOS v2.7, SLP 3.0, EUP-ready, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen function, F3 Shortcut function, and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Manageability | WfM 2.0, DMI v2.0, WOR by PME, PXE |
| Form Factor | ATX form factor: 8.9 in x 6.9 in (22.6 cm x 17.5 cm) |
| Warranty | 2 Year Warranty (Condition applied) |
